Initial commit

FB_tricks.c

+/*  KallistiOS ##version##
+
+    FB_tricks.c
+    Copyright (C) 2024 Donald Haase
+
+*/
+
+/*
+    This example loads a series of png images that are appropriately sized to
+	the display mode into frame buffers and cycles between them. By pressing
+	different buttons you can trigger different effects on that cycling.
+
+	These effects are achieved by manipulating PVR registers and should allow
+	significant time for parallel tasks.
+
+ */
+
+#include <kos.h>
+#include <png/png.h>
+#include <kos/img.h>
+
+/* Init just the basic necessaries */
+KOS_INIT_FLAGS(INIT_IRQ | INIT_FS_ROMDISK | INIT_CONTROLLER);
+
+const char *filenames[] = {
+	"%s/PhillyGENSNL.png",
+	"%s/SteamBoat.png" };
+
+#define FILE_COUNT (sizeof(filenames)/sizeof(filenames[0]))
+
+#define FILE_ROOT "/rd"
+
+#define TIMEOUT_SECS 2
+
+/* These might be something to add into video.c */
+void vid_disable(void) {
+	/* Blank screen and reset display enable (looks nicer) */
+    PVR_SET(PVR_VIDEO_CFG, PVR_GET(PVR_VIDEO_CFG) | 8);    /* Blank */
+    PVR_SET(PVR_FB_CFG_1, PVR_GET(PVR_FB_CFG_1) & ~1);     /* Display disable */
+}
+
+void vid_enable(void) {
+	/* Re-enable the display */
+    PVR_SET(PVR_VIDEO_CFG, PVR_GET(PVR_VIDEO_CFG) & ~8);
+    PVR_SET(PVR_FB_CFG_1, PVR_GET(PVR_FB_CFG_1) | 1);
+}
+
+void vid_shake(char speed) {
+	uint32 bitmapy = vid_mode->bitmapy;
+	int i, j;
+	int shake_dist = 24;
+	int shake_stride = 2;
+
+	printf("Commence the shaking!\n");
+
+	for(i=0; i < 5; i++) {
+
+		for(j=(shake_dist * -1); j<shake_dist; j+=shake_stride) {
+			PVR_SET(PVR_BITMAP_Y, ((bitmapy + j) << 16) | (bitmapy +j));
+			thd_sleep(5);
+		}
+
+		for(j=shake_dist; j>(shake_dist * -1); j-=shake_stride) {
+			PVR_SET(PVR_BITMAP_Y, ((bitmapy + j) << 16) | (bitmapy +j));
+			thd_sleep(5);
+		}
+	}
+
+	/* Go back to start */
+	PVR_SET(PVR_BITMAP_Y, (vid_mode->bitmapy << 16) | vid_mode->bitmapy);
+
+    printf("Shaking completed.\n");
+}
+
+void vid_rotate(int rotations) {
+
+/* If VID_MAX_FB exists, then we're in v2.1.0 and below multibuffer */
+#ifdef VID_MAX_FB
+    uint32 old_base = (fb_base[vid_mode->fb_curr]) & 0x007FFFFF;
+#else
+	uint32 old_base = (vid_mode->fb_size * vid_mode->fb_curr) & 0x007FFFFF;
+#endif
+
+	uint32 stride_div = 8;
+	uint32 stride = ((vid_mode->width / stride_div) * vid_pmode_bpp[vid_mode->pm]);
+	int32 i, dir = 1;
+
+	for(;rotations>0; rotations--) {
+
+		for(i = 0; i<stride_div; i++) {
+			old_base += (stride * dir);
+			/* Set vram base of current framebuffer */
+			PVR_SET(PVR_FB_ADDR, old_base);
+
+				/* Set odd-field if interlaced. */
+			if(vid_mode->flags & VID_INTERLACE)
+				PVR_SET(PVR_FB_IL_ADDR, old_base + (vid_mode->width * vid_pmode_bpp[vid_mode->pm]));
+
+			thd_sleep(16*stride_div);
+		}
+
+		dir *= -1;
+	}
+
+	/* Set back to start value */
+#ifdef VID_MAX_FB
+    old_base = (fb_base[vid_mode->fb_curr]) & 0x007FFFFF;
+#else
+	old_base = (vid_mode->fb_size * vid_mode->fb_curr) & 0x007FFFFF;
+#endif
+
+	PVR_SET(PVR_FB_ADDR, old_base);
+
+	/* Set odd-field if interlaced. */
+	if(vid_mode->flags & VID_INTERLACE)
+		PVR_SET(PVR_FB_IL_ADDR, old_base + (vid_mode->width * vid_pmode_bpp[vid_mode->pm]));
+}
+
+/* This is a replacement for 'vid_flip' that scrolls the FB vertically into an adjascent one.
+   dir sets the direction for it to go 1 for forward -1 for backwards. Any other value will
+   default to forward. If asked to go in a direction with no more FBs, will go the other. */
+/* 1 for forward, -1 for backwards, returns direction in case it has to bounce back or 0 on error */
+char vid_flip_fun(char dir, char stride_div) {
+	/* This requires the new MB concept to work right. */
+#ifdef VID_MAX_FB
+	return 0;
+#else
+    uint32 old_base = (vid_mode->fb_size * vid_mode->fb_curr) & 0x007FFFFF;
+	uint32 new_base;
+	uint32 stride = ((vid_mode->width / stride_div) * vid_pmode_bpp[vid_mode->pm]);
+
+	/* If we don't have multiple buffers set up, just kick back error */
+	if( vid_mode->fb_count == 1 ) return 0;
+
+	/* Lets default to 'forward' */
+	if( (dir != 1) && (dir != -1) ) dir = 1;
+
+	/* Check if we'd roll over in either direction, if so flip direction */
+	if(( ((vid_mode->fb_curr + 1) == (vid_mode->fb_count)) && (dir == 1) ) ||
+		( (vid_mode->fb_curr == 0) && (dir == -1) ))
+		dir = -1 * dir;
+
+	/* Move the fb_curr in the desired direction */
+    vid_mode->fb_curr += dir;
+
+	/* Set the new base address for the fb */
+    new_base = (vid_mode->fb_size * vid_mode->fb_curr) & 0x007FFFFF;
+
+	for(;old_base != new_base; old_base += (dir * stride)) {
+		/* Set vram base of current framebuffer */
+		PVR_SET(PVR_FB_ADDR, old_base);
+
+		    /* Set odd-field if interlaced. */
+		if(vid_mode->flags & VID_INTERLACE)
+			PVR_SET(PVR_FB_IL_ADDR, old_base + (vid_mode->width * vid_pmode_bpp[vid_mode->pm]));
+
+		thd_sleep(16);
+	}
+
+    /* Set the vram_* pointers as expected */
+    new_base = vid_mode->fb_size * ((vid_mode->fb_curr + 1) % vid_mode->fb_count);
+    vram_s = (uint16*)(PVR_RAM_BASE | new_base);
+    vram_l = (uint32*)(PVR_RAM_BASE | new_base);
+
+	return dir;
+#endif /* VID_MAX_FB */
+}
+
+/* Load a single png into the current writable FB */
+int fb_init(int which) {
+	char filename [80];
+	kos_img_t tmp_img;
+
+	/* Compose the current filename */
+	snprintf(filename, sizeof(filename), filenames[which], FILE_ROOT, vid_mode->width, vid_mode->height);
+
+	png_to_img(filename, PNG_NO_ALPHA, &tmp_img);
+	printf("Loading png %i (%s)\n", which, filename);
+	memcpy(vram_s, tmp_img.data, tmp_img.byte_count);
+
+	kos_img_free(&tmp_img, 0);
+
+	return 0;
+}
+
+int main(int argc, char **argv) {
+    uint32 done, start_secs, cur_secs, old_buttons = 0;
+	int f;
+	char dir = 1;
+
+	/* Press all buttons to exit */
+    cont_btn_callback(0, CONT_START | CONT_A | CONT_B | CONT_X | CONT_Y,
+                      (cont_btn_callback_t)arch_exit);
+
+	/* First set the video mode */
+	vid_set_mode(DM_640x480 | DM_MULTIBUFFER, PM_RGB565);
+
+	/* Make sure we have enough FBs to hold the test images */
+	if((FILE_COUNT) > vid_mode->fb_count) {
+		printf("Not enough framebuffers to hold all the files, bailing.\n");
+		return -1;
+	}
+
+	/* Now restrain the framebuffer cycling to the total we can load */
+	vid_mode->fb_count = FILE_COUNT;
+
+	/* Blank the screen so we don't get rapid-fire of the FB's loading */
+	vid_disable();
+
+	/* Load all the files */
+	for(f=0; f < FILE_COUNT; f++) {
+
+		/* If we could load the file, move to the next FB */
+		if(fb_init(f) == 0) {
+			vid_flip(-1);
+		}
+	}
+
+	/* Now that all are loaded, lets reenable the screen */
+	vid_enable();
+
+	/* Lets set a counter that we should rotate through each at least once */
+	done = FILE_COUNT * 2;
+
+	/* Get a timestamp so that we can flip without intervention.
+		any button press will disable this timed system until the next mode. */
+	timer_ms_gettime(&start_secs, 0);
+
+	/* keep drawing frames until start is pressed */
+	while(done) {
+
+		/* Find the first controller and try to get it's state, if it's there */
+		cont_state_t * st = (cont_state_t *) maple_dev_status(maple_enum_type(0, MAPLE_FUNC_CONTROLLER));
+
+		/* If there was a controller state and it is different from our last one, check it out */
+		if((st != NULL) && (st->buttons != old_buttons)) {
+
+			/* Update our last state, this prevents key repeat */
+			old_buttons = st->buttons;
+
+			if(st->buttons & CONT_START) {
+				done = 0;
+				continue;
+			}
+			else if(st->buttons & CONT_A) {
+				vid_shake(-1);
+				start_secs = 0;
+			}
+			else if(st->buttons & CONT_B) {
+				vid_rotate(5);
+				start_secs = 0;
+			}
+			else if(st->buttons & CONT_Y) {
+				dir = vid_flip_fun(dir, 2);
+				start_secs = 0;
+			}
+		}
+
+		/* If the timer is still active lets check it */
+		if(start_secs) {
+			timer_ms_gettime(&cur_secs, 0);
+			if(cur_secs > (start_secs + TIMEOUT_SECS)) {
+				start_secs = cur_secs;
+				//vid_flip(-1);
+				vid_squish(-1);
+				done--;
+				continue;
+			}
+		}
+	}
+
+    return 0;
+}
+

Makefile

+
+TARGET = FB_tricks.elf
+OBJS = FB_tricks.o romdisk.o
+KOS_ROMDISK_DIR = romdisk
+
+all: rm-elf $(TARGET)
+
+include $(KOS_BASE)/Makefile.rules
+
+clean: rm-elf
+	-rm -f $(OBJS)
+
+rm-elf:
+	-rm -f $(TARGET) romdisk.*
+
+$(TARGET): $(OBJS)
+	kos-cc -o $(TARGET) $(OBJS) -lkosutils -lpng -lz -lm
+
+run: $(TARGET)
+	$(KOS_LOADER) $(TARGET)
+
+dist: $(TARGET)
+	-rm -f $(OBJS) romdisk_boot.img
+	$(KOS_STRIP) $(TARGET)
